A customer is installing a new ArubaOS-CX switch The customer does not change the factory default QoS configuration The switch receives an 802.1Q tagged VOIP frame on a port The header contains a DSCP value of EF(46) and the frame has an 802 ip value of 5
How will the switch forward the frame?
(Scenarios may contain multiple errors which may or may not impact the solution )
Refer to the exhibit.
An engineer has attempted to configure two pairs of switches in the referenced configuration It is required to implement VSX at the aggregation layer
The pons of the ArubaOS-CX 8325 switches used for Agg01 and Agg02 are populated as follows:
The configuration of switch AGG01 includes
The VSX cluster is not forming. Which modification should you make to resolve the error condition?
A customer is migrating from a Cisco VSS system to an ArubaOS-CX VSX cluster in order to provide default gateway functionality, the local network administrator creates VLAN interfaces The network administrator then migrates successfully from Cisco to Aruba
The next day a manager asks if the solution is redundant. The network administrator realizes that there is no redundancy on the default gateway functionality
What is the preferred solution with the least amount of configuration and disturbance?
Refer to the exhibit.
Which statement is true?
Refer to the exhibit.
Aruba CX 6300 switch has routes in three different VRFs as per the example above. The user needs to leak routes between VRF Secure and VRF Dev. and also between VRF default and VRF Dev
The customer Is not able to establish routing between directly connected networks 10.100.50.0/24 and 10.102.26.0/24 Which statement is true regarding the routing troubleshooting?
A customer with an ArubaOS-CX 6300M switch is having a performance issue on the network and has received complaints about users experiencing intermittent connectivity. After performing troubleshooting it is determined that many of the local websites on the LAN that users are unable to reach are resolved to an invalid MAC address.
What are the minimum steps that should be performed to mitigate this condition? (Select two)
Company A and Company B are merging their BGP routed networks The companies have overlapping IP ranges and security concerns during the migration phase. Which Aruba CX 8325 functionality would help the merging of networks in a secure way?
How Is voice Traffic prioritized correctly on ArubaOS-CX switches?
The customer is already using Aruba Gateway and third-party L2 switches New ArubaOS CX 6300 switches have been deployed for R&D. which have a requirement for user profiling and tunneled traffic between ArubaOS CX 6300 and Aruba Gateway
What is required for this configuration to apply QoS user-based rules for the R&D client traffic?
